Product Description

MAIN CONFIGURATIONS:

This brewhouse system includes 3 tanks(mash tun/lautering tun, brew kettle/whirlpool, hot liquor tank), please check the details in the following chart.



This is the 200L complete brewing system configuration for your reference.

ITEMS	EQUIPMENT LIST	CAPACITY	QTY
Malt miller	Malt Miller	300kg/h	1
BrewHouse System	Mash& Lautering Tun	200L	1
	Brew Kettle & Whirlpool	200L	1
	Hot Liquor Tank	200L	1
	Plate Heat Exchanger	3m2	1
	Wort pump	3m³/h	1
	Wort Oxygenator		1
	Working platform		1
Fermentation System	Fermentation Tank	200L	6
	Yeast Adding Tank	30L	1
Cooling System	Glycol Water Tank	400L	1
	Chiller	3hp	1
	Clycol water pump	3m³/h	1
CIP Washing System	Alkali Tank	50L	1
	Sterilization tank	50L	1
	CIP water pump	3m³/h	1
Control System	PID control box		1



Heating source: electric, gas fired or steam heating

Material: stainless steel 304 or copper

Warranty: 36 months for tanks





Main specifications of brewhouse and fermentation:

Brewhouse system:

1) - interior wall stainless steel 304, 3mm;

    - exterior wall stainless steel 304 or copper, 2mm

2) - insulation: polyurethane/rockwool 100mm;

    - with inside CIP washing ball

   - agitator

   - removable false bottom

   - sparging arm, sight glass

   -Tangential inlet for whirlpool

   -Thermowell for temperature sensor and thermometer....



Fermentation system:

1) - Interior wall stainless steel 304, 3mm;

     - exterior wall stainless steel 304, 2mm

2) -Dome top, conical bottom,

    -Top manway

3) -Insulation: polyurethane 100mm

4) -Glycol cooling jackets on both cylinder and cone

5) - Inside 360 degree rotating CIP washing ball;

   - CIP arm

  - Bung device

  - safety&vacuum valve on top

  - sample valve

  - rotating racking arm

  - thermometer

  -dry hops port on top

  -carbonation stone (optional)

6) -100% TIG welding with pure argon gas shield

-Interior Finish:Mirror polishing to 0.4~0.6μm without dead corner

-Testing pressure: 3 bar

-working pressure: 1.5-2 bar



Main spare parts:

Pipe line for brewhouse	SUS304
Measuring cylinder	SUS304
Butterfly valve	Ø32
Butterfly valve	Ø38
Sight glass	Ø32
Saccharimeter	0-10; 10-20
Spent grains harrow	SUS 304
Steam solenoid valve	Ø32
Fermenter’s safety valve	Ø51
Fermenter’s Sample valve	ø32
Pressure gauge	0-0.6Mpa
Pipe line for cooling unit	SUS 304
Cooling water solenoid valve	ø32
Cooling pipe insulation
Expansion valve for cooling compressor
Control box cable
Signal wire
Electric relay	Omron
Temperature sensor	PT100



Tips:

1. We have the capacity of 100L, 200L, 300L, 500L, 1000L, 2000L, 3000L, 5000L, 8000L...( 1bbl, 2bbl, 5bbl, 10bbl....) per patch for your reference.

It can be customized, such as the capacity, material, voltage(like 380v, 50Hz, 3phases), heating source, etc.

2. The brewer can also brew draft beer, pale beer, brown beer, stout beer etc,

to meet different taste of customers.



OPTIONAL:

Beer bottling line: bottle washing machine, filling machine, capping machine, labelling machine.

Kegs washer and filler.

Beer kegs(10L,20L,30L,50L...).

Steam boiler.



Company Profile:

We, Jinan Rainbow Machinery Co., Ltd are a professional manufacturer and leading supplier of good quality beer brewing system, ranging from 100L-20000L per patch (used for home, pub/hotel, factory, etc.) at a very competitive price, with product design, production, sales, and installation support.

We have been exporting beer brewing tanks to many places like USA, Canada, Ecuador, Germany, France, Czech Republic, Portugal, Finland, Norway, Switzerland, Australia, South Africa, Kenya, Argentina, Taiwan....etc.



Payment Terms︰ TT/LC
