FEATURES:
-Useful capacity: 15000 litres
-Insulation: polyurethane 100mm
-100% TIG welding with pure argon gas shield
-Cone bottom, 60-72 degree
-Cooling jackets on both cylinder and cone, SUS304, 1.5mm
-Interior Finish: Mirror polishing to 0.4~0.6μm without dead corner
-Dry hopping port on top
-Side mounted manway
-Carbonation stone (optional)
-Safety&vacuum valve on top
-Sample valve on side
-Test Pressure:0.3 Mpa,Working pressure 0.2Mpa.
-Rotating racking arm on cone with butterfly valve
-Discharge arm with butterflyvalve
-CIP arm with 360° coverage CIP spraying ball
-Thermowell with high accuracy temperaturesensor: PT100
Optional:
Capacity scope: 100L to 30000L per patch, can be customized
complete beer brewing system, include malt miller, brewhouse system, fermenting system, cooling system, CIP system, controlling system, filter system.
Beer bottling line: such as bottle filler, washer, capper, labeller.
Kegs washer and filler.
