Configuration of Our Beer Equipment
We provide small and medium brewery equipment for brewers on home and abroad.
Each of the brewing machine we product will be well welded, polished and tested before shipment.
Before you quote,some questions should be kindly confirmed:
1-How many liter beer do you want to brew in a batch?
2-What kind of heating source do you prefer, steam, gas direct fire or electric?
3-Do you need other equipment, such as steam boiler, bottle filling and capping machine, keg filling and cleaning machine, kegs...?
4-What is the electricity voltage in your place?
Here follows is the parameter of our 1000 liter per batch beer equipment, please check for rederence. If you need other configuration, please let us know.
|
NO
|
Equipment
|
Specification
|
Quantity
|
|
Brewhouse system
|
Malt miller
|
|
1
|
|
Mash &Lautering tun
|
1000L
|
1
|
|
Brew Kettle&whirlpool tank
|
1000L
|
1
|
|
Hot liquid tank
|
1000L
|
1
|
|
Plate heat exchanger
|
10m2
|
1
|
|
Wort oxygenator
|
|
1
|
|
Pump
|
3t/h
|
2
|
|
Working platform
|
|
1
|
|
Fermentation system
|
Fermentation tank
|
1000L
|
6
|
|
Yeast adding tank
|
50L
|
1
|
|
Cooling system
|
Cooling compressor |
5P
|
2
|
|
Glycol water tank
|
1500L
|
1
|
|
Pump for cool water tank
|
3t/h
|
1
|
|
CIP Washing system
|
Alkali tank
|
100L
|
1
|
|
Sterilization tank
|
100L
|
1
|
|
Pump
|
3t/h
|
1
|
|
Control system
|
Digital display controlling system
|
1
|
|
Spare parts
|
All the necessary hoses, pipes, valves, clamps/gaskets, thermometer and gauges…etc
|
Spare Parts
|
Our Spare Parts
|
|
Pipe line for brewhouse
|
SUS304
|
|
Measuring cylinder
|
SUS304
|
|
Butterfly valve
|
Ø32
|
|
Butterfly valve
|
Ø38
|
|
Sight glass
|
Ø32
|
|
Saccharimeter
|
0-10; 10-20
|
|
Spent grains harrow
|
SUS 304
|
|
Fermenter’s safety valve
|
ø32
|
|
Fermenter’s Sample valve
|
ø32
|
|
Pressure gauge
|
0-0.6Mpa
|
|
Pipe line for cooling unit
|
SUS 304
|
|
Cooling water solenoid valve
|
ø32
|
|
Cooling pipe insulation
|
|
|
Expansion valve for cooling compressor
|
|
|
Control box cable
|
|
|
Signal wire
|
|
|
SIEMENS frequency convertor
|
V20
|
|
Electric relay
|
Omron
|
|
Temperature sensor
|
PT100
|
Dimension of Our Main Tanks
mash tun, brew kettle: ø1500*2600mm
hot liquid tank: ø1400*2100mm
fermenter tank: ø1200*2500mm
Cooling tank 1500L: ø1600*1600mm
Company Information
We, Jinan MIBE Machinery Co.,Ltd & Jinan Rainbow Machinery are a professional manufacturing and trading company for good quality Beer Brewing Systems, ranging from 100 liter to 10000 liter per batch, which is used for home, Bar/Pub, Restaurant, Hotel and Small Beer Factory.
- Brewhouse System
- Fermentation System
- Cooling System
- CIP System
- Control System
- Filtration System (need or not?)
- Bottle Machines (need or not?)
- Keg Machines (need or not?)
- Beer Tower (need or not?)
- Kegs (need or not?)
Clients' Country
Germany, Czech Republic, USA, Canada, Russia, Sweden, Paraguay, Singapore, Australia, Finland...
Feature
1-Brew all kinds of beer: pale beer, brown beer, stout beer....
2-Customized parameter: a. capacity(100L, 200L, 300L, 500L, 1000L, 10BBL, 2000L, 3000L...)
b. voltage(220v or 380v or other electricity voltage )
c. material thickness(our standard is inner wall 3mm sus304, outer wall 1.5mm sus304, insulation 100mm PU or rock wool)
d. dimension of all the tanks(length, height, width)
e. heating source(electric, steam, direct gas fire heating)
3-Water and Pressure Test is made before shipment.
Our Service
1. We can provide services such as product design( we recommend suitable equipment as per your budget), beer tank layout, installation and training of beer fermentation...
2. We also provide bottle filling and washing machine, keg filling and washing machine, label machine, keg and steam boiler as per your requirement
3. 36 months for the main tank
Equipment Images
Polishing and Welding
